Item No.: RS-VAL300G
Hopper Loader/Euro Auto Loader/Automatic Vacuum Loader
E-mail:15113320579@vip.126.com
Home Page
Description of the Euro automatic hopper loader,
Euro design with stainless steel hopper to avoid material from any pollution, in addition, it has an attractive and polished appearance and a soundproofed motor cover to reduce noise level. And convenient to move. Remote operation becomes simple and convenient by using of a detachable control panel.
The Euro automatic hopper loader has the following features,
300G STAND ALONE TYPE AUTO LOADERS
STAND ALONE TYPE AUTO LOADERS FEATURE
With small footprint and low weight, available of being placed directly onto other machines or containers for auto loading. Microcomputer controlled.
Alarm for overload and lack of material.
300G equipped with high-speed rectifier motor with delicate size and strong suction force-suitable for new materials. 400G with induction high pressure pump--with low noise and long service time.
Cable control board design-easy to set and control with distance.
Filter for air and dust.
Specification of the hopper loader,
|
Model
|
RS-VAL300G |
|
Motor
|
Type
|
Carbon Brush
|
|
Specification
|
1.1KW/1.3HP 1⊙
|
|
Conveying Capacity(Kg/h)
|
300
|
|
Loading Distance(m)
|
3.5
|
|
Static Wind Pressure(mm/h2o)
|
1300
|
|
Reservoir Volume(L)
|
6
|
|
Conveying Tube Inner Diameter(mm)
|
⊙38
|
|
Specification Of The Attached Hoses(mm)
|
⊙38mmX3.5m l pc
|
|
Dimension(cm)
|
38 X 28 X 58
|
|
Approx.Net Weight(KG)
|
12
|
Machine color--- blue or gray white, or others;
Machine brand--- factory brand, OEM brand or no brand;
We do OEM!
We do B2B, B2C!
